MACHINE GUN ML-W - LASER WELDING MACHINE
Description
MACHINE GUN ML-W by Military Laser
🔧 Maximum Performance and Precision in Laser Welding for Metals
Engineered for peak industrial performance, the MACHINE GUN ML-W delivers unmatched precision and durability in laser welding. Built to maximize operational efficiency, it provides robust, high-quality welds for even the most complex metal components.
✅ Precise, strong, and clean welds
✅ Optimized for heavy-duty industrial use
✅ Ideal for demanding applications
👉 Perfect for construction, automotive, shipbuilding, and metallurgical industries.
🔧 Key Features & Capabilities
| 🧰 Function | ✅ Description |
|---|---|
| 🔩 Laser Welding | Delivers clean, durable, and aesthetically precise welds on all types of metals. |
| ⚙️ Industrial Build | Heavy-duty construction suitable for continuous, high-volume operation. |
| 🎯 Precision Control | Stable and accurate welds, even on thin or complex metal geometries. |
| 🛡️ Durability | Designed to withstand harsh environments and extended use without degradation. |
🛠️ Applications Across Industries
-
🏗️ Construction: Welding beams, gates, and structural metal components.
-
⚙️ Metallurgy: Joining parts for manufacturing and post-processing.
-
🚢 Marine: Welding hulls, frames, and marine-grade structures with corrosion resistance.
-
🚗 Automotive: Body panels, engine mounts, and precision structural parts.
🧼 ML-Cleaner – Configuration & Technical Specifications
| 🔧 SPECIFICATIONS | ⚡ MLC 1500W | ⚡ MLC 2000W | ⚡ MLC 3000W |
|---|---|---|---|
| 🔦 Laser Source | IPG Photonics | IPG Photonics | IPG Photonics |
| 📏 Optimal Operating Distance | 1200 ± 5 mm | 1200 ± 5 mm | 1200 ± 5 mm |
| 🎯 Beam Diameter | 0 – 5 mm | 0 – 5 mm | 0 – 5 mm |
| 📶 Modulator Frequency | 1 – 200,000 Hz | 1 – 200,000 Hz | 1 – 200,000 Hz |
| 🔌 Fiber Cable Length | 10 – 25 m | 10 – 25 m | 10 – 25 m |
| ⚡ Power Consumption | 5500 W / 25 A | 7000 W / 32 A | 9500 W / 25 A |
| 🔬 Fiber Core Diameter | 50 μm | 50 μm | 50 μm |
| 🔫 Welding Torch | ML-Usys-Wired | ML-Usys-Wired | ML-Usys-Wired |
| ❄️ Water Cooling System | Marrshal T – Water Chiller | Marrshal T – Water Chiller | Marrshal T – Water Chiller |
| ⚖️ Gun Weight | 1500 g | 1500 g | 1500 g |
| 🧪 Shielding Gas | N₂ / Argon | N₂ / Argon | N₂ / Argon |
| 📐 Machine Dimensions (mm) | 1200 × 650 × 1200 | 1200 × 650 × 1200 | 1200 × 650 × 1200 |
| 🏋️ Machine Weight (kg) | 250 | 270 | 320 |
| 🔋 Operating Voltage | 220V ± 20% / AC / 50Hz | 380V ± 20% / AC / 50Hz | 380V ± 20% / AC / 50Hz |
